RBB 1000.2H

Glass drill with opposing bits, featuring automatic lower bit drilling and manual upper bit drilling.
Automatic sheet locking during drilling. Regulation of lower bit penetration depth. Variable-height glass support top, from 1000x800 mm to 1800x1200 mm. Manual adjustment of diamond tool speed by means of belts.
TECHNICAL SPECIFICATIONS:
  • Minimum drilling diameter 4 mm.
  • Maximum drilling diameter (with 2 bits) 130 mm.
  • Maximum drilling diameter (with 1 bit) 200 mm.
  • Max drilling thickness 50 mm.
  • Throat depth 1000 mm.
  • 8-speed diamond tool rotation drive.
  • Installed electrical power 2.5 kW.
  • Machine weight: 320 Kg.
OPTIONALS:
  • Glass support bench with castors for sheet positioning.
  • Laser alignment system.
  • Tank and pump for water re-circulation.
  • Supports for in-series drilling.

N.B. The RBB 1000.2H is also available in a version with upper bit only (type RBB 1000.1H).
